Plastics Shrinkage Rate & Mold Shrinkage Rate

It is very important for each product design to know the plastics shrinkage rate. So that when he designs his parts design, he can present the right scale size of the drawing to mold manufacturing factory like Intertech.

Intertech provides here with the referenced of the most common used plastics shrinkage rate chart to help the product designer to double check their product design. Intertech will provide our experience for helping customer to select the right plastics for their project. Welcome to discuss with Intertech for any

Plastics material shrinkage rate application

Mold Shrinkage Rate

Meanwhile, the mold shrinkage rate corresponses the material shrinkage rate and provides good information for production injection molding factory for calculating the final finished product size to be formed in final shape.

Intertech’s mold design and engineering team is quite profession in helping customer to double check this correspondence and build the best mold, product the best finished for customer. Welcome to discuss us with your project.

Plastics Shrinkage Rate
General Plastics	Shrinkage Rate (%)
General Plastics	Raw Material	Add. 30% GF
LDPE	2.0	0.5
HDPE	2.0	0.4
PP	1.8	0.4
PS	0.6	0.1
PVC	0.4	0.1
PMMA	0.5	0.1
ABS	0.6	0.1
Engineering Plastics	Shrinkage Rate (%)
Engineering Plastics	Raw Material	Add. 30% GF
NY6	1.5	0.4
NY66	1.5	0.4
PBT	2.0	0.4
POM	2.5	0.5
PC	0.6	0.1
PPO	0.6	0.1

Mold Shrinkage Rate
Plastics	Glass Fiber Adding	Mold Shrinkage Rate
Plastics	[%]	[%]
PS		0.3-0.6
HI-PS		0.5-0.6
SAN		0.5-0.7
ABS		0.4-0.7
ASA		0.4-0.6
LDPE		1.5-5.0
HDPE		1.5-3.0
PP		1.0-2.5
PP+GF	30	0.5-1.2
PVC-soft		>0.5
PVC-rigid		0.5
PVDF		3.0-6.0
PMMA		0.1-0.8
POM		1.9-2.3
PPO		0.5-0.7
PPO+GF	30	<0.7
CA		0.5
PC		0.8
PC+GF	10~30	0.15-0.55
PBT		1.5-2.5
PBT+GF	30-50	0.3-1.2
PA6		0.5-2.2
PA6+GF	30~50	0.3-1
PA66		0.5-2.2
PA66+GF	30~50	0.5-1.5
PA11		0.5-1.5
PA12		0.5-1.5
PPS	40	0.2
